    High Density Interconnect HDI PCB Board 0.8mm 4L Resin Filled

    High Density Interconnect HDI PCB Board 0.8mm 4L Resin Filled


    HDI PCB Board PCB Board Fabrication High Density Interconnect HDI PCB Technology HDI Printed Circuit Board


    4L 1+N+1 HDI Boards


    HDI PCB means high density interconnect printed circuit boards, they are characterized by finer lines, closer spaces, and more dense wiring.
    Due to its higher circuit density than traditional circuit boards, HDI PCB designs can include smaller through holes and capture pads, as well as higher connection pad density. HDI PCB is widely used to reduce the weight and overall dimensions of products, as well as to enhance the electrical performance of the device.


    HDI Board Stack-up:
    1+N+1 with laser microvia and mechanical buried core via. The “1” represents “build-up” or sequential lamination on each side of the core.
    i+N+i (i>=2) PCBs contain 2 or more “build-up” of high-density interconnect layers. Microvias on different layers can be staggered or stacked. Copper filled stacked microvia structures are commonly seen in challenging designs.

    HSX products cover 1~32L FR-4 PCB, IMS PCB,HDI Boards, high frequency PTFE boards and Rigid-flex boards etc. It provides flexible quick turn production services (12 hours to72 hours), as well as small volume to big volume PCB manufacturing.Products are widely used in high-tech fields such as communications, power supplies, computer networks, digital products, industrial control, science and education, medical devices, and aerospace.


    Circuit board Layer count:4LCircuit board laminate:FR4 TG170
    Layer Copper thick:1/H/H/1OZBoard thickness:0.8MM
    Smallest hole size:0.15mmSmallest PCB track/gap:0.06/0.06mm
    Solder mask color:TAIYO BlueSilk screen color:None
    PCB surface finished:Immersion GoldBoard profile:Routing/V-CUT
    PCB Board Application:digital products
    Requesting Special requirement:small line space and gap:2.5/2.5mil/HDI Buried vias and blind vias, one step stack up /min. via hole size 0.15mm/impedance control/resin filled and plated over
